Options & specification

Explore
Standard specification

What every
X1 includes.

The full standard specification every X1 leaves the factory with — before a single option is added.

Performance
Power144 kW — 500 hp/tonne195 hp — 500 hp/tonne
Top speed235 km/h145 mph
0–100 km/h0–60 mph3.0 s2.9 s
0–200 km/h0–124 mph8.0 s
Lateral forceUp to 3.0 G+
Braking decelerationUp to 3.0 G+
Chassis & suspension
ChassisFormed 4130 chromium-molybdenum alloy steel
SuspensionIndependent wishbone
ActuationPushrod / bell-crank / inboard shock
DampersJRI mono-shock coilover aluminium dampers
AdjustabilityToe, camber and sway-bar and ride height
Engine
Engine'Hyperbusa' — 1340 cc Gen 2 Hayabusa, built by Hyper Racer
Gearbox6-speed sequential
Body
Front & rear wingsVacuum-infused carbon-fibre, angle adjustable
Ground-effects undertrayVacuum-infused carbon-fibre
Front wing end platesWet-laminated fibreglass for easier DIY repairs
Side pods, nose cone & intake panelsFibre-reinforced composites, vacuum-infused
Side intrusion protection10mm carbon / Diolen vacuum-infused panels
Cockpit
SeatCarbon-fibre / Kevlar vacuum-infused
Head restraintCarbon-fibre / Kevlar vacuum-infused
Overhead protectionHenry Bar OHP system
Harness6-point safety harness
Steering systemHyper Racer rack & pinion, column and quick-release boss
Steering wheelCarbon-fibre Formula steering wheel
ShifterSequential hand shifter
ClutchCockpit hand clutch
Brake biasCockpit adjustable
DashAIM Solo 2 DL with K-line ECU integration
Shift lightsShift-P2
Pedals2 pedals (throttle & brake) — adjustable reach and angle
MirrorsSpa Design formula car mirrors
Fuel tankAluminium 20 litreAluminium 5.3 gallon
Paint & graphics
Carbon finishGloss or satin clear over carbon
Painted finishGloss or satin black or white over fibreglass
DecalsHyper Decal Pack supplied
Size & weight
Length4000 mm157 in
Width1835 mm72 in
Height1000 mm39 in
Wheelbase2425 mm95 in
Dry weight — race events410 kg905 lbs
Tyres & wheels
TyresFront 180/550R13 · Rear 240/570R13
WheelsAluminium 3-piece
Front rim dimensions13" × 9" — suits 8" wide tyres
Rear rim dimensions13" × 11" — suits 10" wide tyres
Final drive
DifferentialHyper Racer ATB LSD
Driveshafts & CV jointsHyper Racer driveshaft w/ 6-bolt CV joints
ChainD.I.D Super Street 530ZVM-X2
Brakes
CalipersWilwood 4-piston universal caliper
Disc rotorsHyper Racer floating 280 mm cross-drilled rotorHyper Racer floating 11 in cross-drilled rotor
Master cylinderTwin split system
Available options

Every option,
explained.

Grouped the way we build the car. Standard items are included in every X1; Optional items can be added. Hover any option for the detail behind it.

The Hyper Racer X1
Built to your spec
01 Body construction
Woven Glass body
Standard

XE650 infused woven glass. Lighter and stronger than standard fibreglass. Painted in your chosen colour.

Full Carbon body
Optional

Carbon-fibre side pods, nosecone, rollbar fairings, headrest and knee protector. Weight saving for serious racing, with a gloss or matte clear carbon finish.

02 Engine preparation
Core Reliability Rebuild
Standard

Second-hand Hayabusa unit rebuilt to one common spec: main and big-end bearings replaced, Gen 1 valve springs, Hyper Racer billet clutch cover and billet sump with baffle plate.

Extended Internal Refresh
Optional

Everything in the Core Reliability Rebuild, plus pistons and rings replaced and clearanced, connecting rods replaced, and head valves replaced with clearances checked.

03 Air Jack Upgrade
Integrated Air Jack system
Optional

Lifts the car in seconds. Paired with the service trolley, you can drop the car onto its castor wheels and roll it anywhere in the pits, garage or workshop on your own.

Service Trolley
Optional

Whether lifting the car with a trolley jack or air jacks, placing it onto the low-profile service trolley lets you easily move the car around the garage, pits or workshop.

04 Safety & FIA pack
FIA Side Protection Panels — Diolen/Carbon
Standard

10 mm Carbon/Diolen side intrusion panels, fitted as standard. Generally mandated for racing and provide crucial impact protection.

Fire Extinguisher — Plumbed System
Optional

A plumbed-in suppression system for additional fire protection, buying the driver more time to get out in the event of a fire.

05 Drivetrain & mechanical
Rekluse Centrifugal Automatic Clutch
Optional

A centrifugal automatic clutch — pull away without touching the hand clutch, engaging automatically as the revs rise.

Engine Starter Motor Upgrade
Optional

Converts the standard Hayabusa starter to a conventional throw-out starter. Keeps the starter disconnected from the crank at all times, preventing damage in the event of a spin, with additional cranking power and better engine sealing.

Reverse Gear System
Optional

A geared reverse motor driving a secondary output-shaft gear, engaged by pressing and holding a button. Some governing bodies mandate a reverse gear.

06 Paint & graphics
Custom Paint and Decals
Optional

The car comes painted with factory decals as standard. Choose this for custom paint or decals beyond the standard two-colour configuration.
